Heavy Duty Easy Debugging ON-OFF Quarter Turn Small Motorized Actuator For Ball Valve
Description
TG-R series small quarter turn electric actuator is newly designed to operate small size ball valve, butterfly valve, plug/damper valves and automation of rotary machines. The compact design of the small quarter turn electric actuator and the rugged, firm corrosion-resistant housing will be your best choice. TEKO has more than 10 years of experiences in the field of fluid control industry. We expect to cooperate with you in the near future.
Feature
Torque range:30~5000N.m
Switching time:20~200 S
Ambient temperature:-30℃~+60℃
Control method:On-off / modulating type/ Intelligent type
Weight:2.1 KGS~68 KGS
Protection:IP67, (IP68 optional)
Voltage:AC110~265V , AC / DC 24V Multi voltage input
Single phase: AC220V / AC110V / AC24V / DC24V
Applicable valve : Ball Valve (DN15-DN200); Butterfly Valve (DN25-DN400)
Material of Actuator Body: Aluminium Alloy
1. Compact design:Small, light and compact design, high torque and various control option will meet your specific requirement.
2. Firm corrosion-resistant housing: The shell is made of aluminum alloy, with anodic oxidation treatment and polyester powder coating. It is strong corrosion-resistant and enclosure IP67,NEMA 4 and 6, IP68 is optional.
3. Wide torque range:The torque of TG-R small quarter turn electric actuator is form 30Nm-5000Nm.
4. Circuit:Controlling circuit meets the single-phase or three-phase power supply standard, circuit layout is reasonable and compact, terminals meet various of additional functional requirements effectively.
