PFA Lined Spring Loaded Poppet Check Valve For Non - Return Function

Brand Name : TEKO

Model Number : H71F46

Certification : CE/PED, API

Place of Origin : Made in China

MOQ : 1 piece

Price : By negotiation

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 200 tons per year

Delivery Time : 15 working days after deposit

Packaging Details : By export wooden cases

End Connection : Wafer

Installaiton : Horizontal or Verticval

Applications : Aggressive Or Toxic Liquid

Liner : PTFE, FEP, PFA

Structure : Poppet Type

Design Standard : GB 12236

Contact Now

PFA Lined Spring Loaded Poppet Check Valve For Non-return function

Basic Info

Type Wafer Poppet Check Valve
Diameter DN25~400MM
Lining PFA/FEP
Nominal Diameter DN25~300MM
Connecting Format Butt Clamp
Working Temperature Normal Temperature
Applicable Medium Corrosive Medium, Oil, Steam, Water
Flow Direction Unidirectional
Type Direct Connection
Driving Mode Spring Loaded
Application Non-return, clear water hammer
Material Carbon Steel
Sealing Form PTFE Seat
Structural Style Lift

Features

  • Guided spring and poppet - secure from misalignment
  • Crush resistant design guards against installation abuse
  • Ideal design for low pressure duties
  • Full bore design provides maximum flow with minimum pressure drop
  • Stainless Steel spring as standard, poppet lift pressure 14 mbar, other materials under request
  • Designed for easy disassembly

Technical Specification

  • Design and Manufacture Standard: ASME B16.34, HG/T 3704
  • Face-to-face Dimension: ASME B16.10 , GB/T 12221
  • Flange Standard: ASME B 16.5 ,GB/T 9119 ,DIN ,JIS
  • Inspection and Testing: API 598, GB/T 13927

PFA Lined Spring Loaded Poppet Check Valve For Non - Return Function
